Caracteristicas Galería Descripción de producto Pida una cita

Caracteristicas

Especificaciones

Color: green

Boom: Optional

Insulation grade: F

motor: Variable Frequency Motor

voltage: 220V/110VÂ±10%

Usage: Road Traffic Safety

Warranty: 1 Years

Feature: High Durable

certificate: CE,ISO9001

Keyword: barrier gate

Información básica

Certificación: CE,ISO9001

Pago y Envío Términos

Packaging Details: carton or wooden case

Supply Ability: 10000 Set/Sets per Month barrier gate

Descripción de producto

Product Description

WEJOIN Eco-Grade Servo Barrier Gate WJDZE

DC Brushless Servo Motor
Higher Stability, Longer Sercive Life and Easier Operation

Boom-Type Selection

Model

WJDZE (speed 3-5s adjustable)

Running Speed

Max Boom Length

4.5m

Boom Type

straight

90 ° folding

180 ° folding

2 fence

3 fence

Model

WJDZE1 (speed 1.8-6s adjustable)

Running Speed

1.5s

5/6s

Boom Type

straight

90 ° folding

180 ° folding

2 fence

3 fence

Max Boom Length

4.5m

Input Voltage

AC 220V±10%, AC110V±10%

Frequency

50/60HZ

Motor Voltage

DC 310 V

Enclosure Rating

Ip54

MTBF

3000000 times

Traffic Flow Application

1500 times / 24hours

Working Motor Power

-35°C~+85°C

Max Motor Power

120W

Max Motor Speed

240N.m

Functions & Features

1). No clutch design: open the barrier gate by manual handwheel when power-off.
2). No limit switch design: the motor can detect the boom position automatically.
3). Self-detect after power-on, open/close speed is adjustable.
4). With auto-reversing on obstruction function.
5). An infrared photocell interface is available. (need to install photocell device)
6). A loop detector interface is available, to avoid hitting the vehicle, and control the boom falling down automatically after
vehicle passing. (need to install loop detector)
7). Build-in delay auto-closing function, coordinated with counting function.
8). With auto-aging test function.
9). NO/NC wire control signal inputs are optional.

Packing & Delivery

Manufacturing Technique

Company Profile

SHENZHEN WEJOIN MECHANICAL & ELECTRICAL CO., LTD.

Shenzhen WEJOIN Mechanical&Electrical Co. was founded in 2004. It is the first national high-tech enterprise specialized in research and development, manufacturing, and sales of intelligent access control products in China. As one of the Brand Business Enterprises of Guangdong province, WEJOIN so far is also one of the largest manufacturers in access control and management product. Its main products include automatic barrier gates, tripod turnstiles, flap barriers, swing barriers, etc. All the products have CE certificates and have been exported to more than 100 countries or regions, such as Germany, British, Spain, Czech, France, Malaysia, India, and so on.

Certifications

Exhibition

FAQ

Q1: What are your main products?
A: Its main products include automatic barrier gate, tripod turnstile, flap barrier, swing barrier, etc.
Q2: Are you a manufacturer? Do you provide ODM / OEM service?
A: Yes, we are a manufacturer. WEJOIN provides professional customized services for global clients.
Q3: I would like to ask if this is with an RFID card reader and controller?
A: Yes, there is a controller, our barrier gate can connect with an RFID card reader.
Q4: What boom types of your barrier gate?
A: We have 1s with 3m barrier arm, 3s with 4.5m barrier arm, 6s with 6m barrier arm, etc
Q5: What is your MOQ?
A: Any quantity is acceptable.
Q6: How much is 1 set? Can provide product details? How fast and how much it would cost to ship this item?
A: Please Click here and send your inquiry, then we will send you the price and details in time.
Q7: How about the payment option?
A: 30% by T/T, 70% by T/T before delivery.
Q8: Do you have a model that can be used outdoors without further shelter?
A: Yes, It can be used outdoor without shelter. But product life will be longer with shelter.
Q9: How much warranty time do you have?
A: Within one year, if any problems, we will offer the accessories.
Q10: Do you use WeChat? Can we please talk on WeChat? or WhatsApp?
A: Yes, my WeChat ID FZ15002051250, my phone number/WhatsApp is +86 15002051250, my skype ID wejoin09.
